Benefits of Micropiles

Advantages of cased micropiles over standard micropiles

• Increased Load Capacity: These micropiles boast higher compression, tension, and shear capacities compared to standard ones due to a reinforced steel casing. This additional strength facilitates the transfer of heavier loads through weaker soils to stronger strata.
• Versatility in Various Soil Conditions: They can penetrate a broad spectrum of soil types and conditions, from loose soils to solid rock. The steel casing mitigates the risk of cave-ins in loose soil, ensuring stability during drilling.

Benefits of Driven Foundation Elements

• Smaller Equipment and Reduced Spoil Volume: Installation requires smaller drilling equipment, lowering project costs and enabling access to confined areas. Moreover, cased micropiles generate less spoil, minimizing excavation and disposal needs, which is advantageous in urban or space-limited environments.
• Minimal Vibration and Disturbance: Installation without driving results in minimal vibration, making them suitable for projects where vibration must be minimized, such as slope stabilization or near sensitive structures like historic buildings.
• Suitable for Restricted Access: With their small diameter, cased micropiles are well-suited for projects with limited access, such as strengthening existing building foundations. Their installation in tight spaces or areas with restricted access enables retrofitting or upgrading existing structures without major disruption.

Applications of Cased Micropiles

HOW MICROPILES ARE USED IN CONSTRUCTION PROJECTS

• Foundation Support: These micropiles are widely employed in both new construction and retrofitting projects to transfer heavy loads from structures to underlying soil or rock. They are suitable for various structures like buildings, bridges, towers, and industrial facilities.
• Slope Stabilization: Effective in stabilizing slopes and preventing soil erosion by reinforcement at various angles and depths. They help prevent landslides and maintain the integrity of embankments, hillsides, and cut slopes.
• Underpinning: Used for reinforcing existing structures in limited access areas without significant disruption. Cased micropiles reliably strengthen foundations and enhance load-bearing capacity.
• Retaining Walls: Ideal for constructing stable retaining walls, whether vertical or angled, to resist lateral forces and support retained soil.
• Bridge and Infrastructure Projects: Commonly employed in challenging soil conditions where deep foundations or limited access are required.

Design and Installation of Cased Micropiles

• Small Diameter: With a diameter typically under 300mm (12 inches), cased micropiles can be installed in tight spaces and areas with restricted access. Their compact size also reduces excavation needs, making them suitable for projects with limited space.
• High Load Capacity: Cased micropiles boast a significant load capacity advantage over standard ones, thanks to the presence of a high-strength steel casing. This additional strength enables them to withstand heavy loads, meeting the requirements of structurally demanding projects.
• Versatility Across Soil Types: These micropiles can penetrate various soil types, from loose soils to solid rock, without the risk of cave-ins. The steel casing ensures stability during drilling, making them adaptable to different geotechnical settings and suitable for a wide range of projects.
• Minimal Vibration: Installed without driving, cased micropiles minimize vibration during construction. This feature is especially beneficial for projects where vibration needs to be minimized, such as slope stabilization or near sensitive structures like historic buildings. Reduced vibration helps maintain environmental stability and ensures the safety of nearby structures.

Benefits of Cased Micropiles for Soil Stabilization

• Enhanced Load Transfer: Utilizing the combination of casing, grout, and reinforcement to enhance load transfer capabilities. The steel casing provides additional strength and stability, while the grout and reinforcement contribute to the load-bearing capacity. This enhanced load transfer allows cased micropiles to effectively transmit loads through weak soils to stronger underlying strata.
• Mechanisms for Transferring Axial, Tensile, and Shear Loads: Designed to transfer different types of loads, including axial, tensile, and shear loads. The steel casing, filled with grout and reinforcement, acts as a column element with significant axial capacity. It provides resistance against compressive forces and ensures the stability of the micropile. Additionally, the grout-filled steel casing offers greater shear capacity compared to other micropiles, making it suitable for resisting lateral forces and shear loads.
• Increased Depth Capabilities: Depending on various factors such as soil stiffness, casing diameter, wall thickness, and steel strength, cased micropiles can extend to depths of up to 250 feet. This increased depth capability allows for the installation of cased micropiles in deeper soil layers or when encountering challenging soil conditions. It provides flexibility in designing foundations for projects that require deeper support.

Maintenance and Inspection of Micropiles

Best Practices for Ensuring the Longevity and Performance of Micropiles

To ensure the longevity and performance of micropiles, regular maintenance and inspection are essential. This includes periodic visual inspections to check for any signs of damage or deterioration. It is also important to monitor the performance of the micropiles through load testing and instrumentation. Any necessary repairs or maintenance should be promptly addressed to prevent further issues. Additionally, proper drainage and soil management around the micropiles can help minimize the risk of corrosion and ensure their long-term effectiveness.
